ZEBRA ZXP SERIES 9 CARD PRINTERS

PAIRING OUTSTANDING PRINT QUALITY WITH FAST PRINT SPEEDS

Extending Zebra’s line of card printers, the ZXP Series 9™ is a retransfer card printer specifically engineered for high-security applications. With industry-leading throughput enabling you to print more cards faster and with outstanding quality. Take control with the printer’s user-selectable print quality mode, allowing you to optimize for print speed or sharpen print quality. And, the dual-sided, simultaneous retransfer process provides best-in-class printing, encoding and laminating throughput.

QUALITY, DEPENDABILITY, FLEXIBILITY AND SPEED

Government, Education, Retail and Hospitality industries have an ever-increasing focus on security, a need for flexibility and a continual demand for efficiency.

Outstanding Print Quality + Fast Print Speeds

Produce durable, long-lasting, tamper-resistant cards with the sharpest photo-like image quality that boasts rich, consistent colors and strikingly sharp resolution. Industry-leading throughput allows you to print more cards faster—even with dual-sided lamination and encoding.

ZXP SERIES 9 SPECIFICATIONS

Printing

• Dye diffusion retransfer
• Full color or monochrome retransfer printing
• Single- and dual-sided printing
• Max Print Speed Single-Side*:
  180 cph (with 300 dpi)
  125 cph (with 600 dpi)
• Max Print Speed Dual-Sided*:
  190 cph (with 300 dpi)
  140 cph (with 600 dpi)
• Photo-quality images
• Over-the-edge printing on standard CR80 media

Standard Features

• USB and Ethernet connectivity
• Single-card feed capability
• 150 card capacity feeder (30 mil)
• 15 card capacity reject hopper (30 mil)
• 100 card capacity output hopper (30 mil)
• i Series™ intelligent media technology
• Auto-calibration of media
• 21-character, 6 line LCD operator display
• Print Resolution: 300 dpi or 600 dpi
• 2GB memory standard
• Lifetime warranty on printhead
• 2-year limited warranty on printer
• Microsoft® Windows certified drivers
• Kensington physical lock capable

Laminator Specifications

• Single-or dual-sided lamination option (with dual-sided printer only)
• 180 cards per hour dual-sided printing and dual-sided lamination
• GSA FIPS 201 approved (dual-sided lamination)
• Uses Zebra True Secure i Series laminates only
• Laminate for the top and bottom sold separately
• Custom-coded laminates available
• Custom holographic laminates available
