LG Digital Signage Display | 65″, 55″, 49″ | UH7F Series

PANEL

• Screen Size 65″Panel Technology IPS
• Aspect Ratio 16 : 9Native Resolution 3,840 x 2,160 (UHD, RGB)
• Brightness(Typ.,cd/m²) 700Contrast Ratio 1,100:1
• Viewing Angle (H x V) 178 x 178Response Time 8ms (G to G)
• Surface Treatment (Haze) Haze 3%Life Time (Typ.) 50,000 Hrs
• Operation Hours 24 HrsOrientation Portrait & Landscape

CONNECTIVITY

• Input HDMI (3), DP, DVI-D, Audio, USB 2.0Output DP, Audio (Off/Fixed/Variable)
• External Control RS232C In/out, RJ45 (LAN) In, IR In

MECHANICAL SPECIFICATION

• Bezel Color BlackBezel Width 9.9mm(T/R/L), 14.4mm(B)
• Monitor Dimension (W × H × D) 1,453.3mm x 844mm x 39.9mmWeight (Head) 28.2 kg
• Carton Dimensions (W × H × D) 1,600mm x 1,095mm x175mmPacked Weight 35.0 kg
• Handle NoVESA™ Standard Mount Interface 300 x 300

UH7F Series

• Brightness(Typ.) : 700 cd/m²
• Bezel : 9.9 mm (T/R/L), 14.4 mm (B)
• Depth : 39.9 mm
• Interface : HDMI(3)/DP/DVI-D/USB 2.0/ RS232C/ RJ45/ Audio/ IR
• Built-in Speaker and Detachable Logo
• 30º Tilting Installation

Available Sizes:

• 65″
• 55″
• 49″
